The product relies entirely on its own equipment, maintaining a
navigation accuracy within 100 meters throughout the entire journey without depending on satellite navigation signals, allowing UAVs to reach their designated targets with confidence.
• Engineered for reliability, the product excels in harsh terrains such as deserts and Gobi landscapes, delivering stable and accurate navigation.
• Compact, lightweight, and quick to deploy with no setup time, it is ready for immediate use—perfect for dynamic battlefield conditions where adaptability is crucial.
| Model A | Model B | Model C | |||||||
| Anti- interference ability |
Suitable for any electromagnetic interference environment | Suitable for GNSS-denied environment for less than 20mins or 30km |
|||||||
| Applicable area | All land landforms (including rivers, lakes, and streams) |
All areas except for the wide sea surface |
All land landforms (excluding wide rivers, lakes, and streams) |
||||||
| Climate | Day and night, all weather conditions except for strong rain, snow, or dense fog |
All weather conditions | Day and night, all weather conditions except for strong rain, snow, or dense fog |
||||||
| Applicable height |
Below 3,000 meters, flying in the cloud base |
1,000—10,000 meters | 300–1,200 meters, flying in the cloud base |
||||||
| Flight duration | No limit | No limit | 20 minutes | ||||||
| Flight range | No limit | No limit | 30km | ||||||
| Flight speed | Less than 100m/s | Less than 300m/s | Less than 100m/s | ||||||
| Position accuracy |
The overall error is less than 100 meters |
The overall error is less than 100 meters |
The overall error is less than 70 meters |
||||||
| Volume | ≤100mm×80mm×70mm | ≤200mm ×150mm ×150mm | ≤60mm×30mm×20mm | ||||||
| Weight | ≤700g | ≤1500g | ≤250g | ||||||
| Data interface | RS-422 、RS-232 、TTL 、 Network port, choose from the above options | ||||||||
| Protocol | Can be customized according to user requirements | ||||||||
| Data frequency | 1-5Hz | ||||||||
| Working band | Infrared 8-14 µ m; Laser 1.54 µ m | ||||||||
| Power consumption |
≤20W | ≤20W | ≤15W | ||||||
| Working temperature conditions |
-20℃~ +50℃ | -50℃~ +70℃ | -20℃~ +50℃ | ||||||
| Can be expanded according to user requirements | |||||||||
